Our tractor unit introduces the European advanced technology of truck. In respect of its particular and attractive appearance, continuous reliability and high security in consistency with European standard, it leads the truck industry of China to move on a new stage. This product is configured with the exclusive axle, chassis and cab painting, durable frame and it makes the drivers comfortable and joyful, becoming the optimal choice of users.

Tractor Unit
Technical Parameters
Model GENLYON CQ4185HTVG351
Driving Type 4×2
Weights Gross Vehicle Weight (kg) 18000
Kerb Weight (kg) 6870
Max. Fifth Wheel Payload (kg) 11000
Max. Towed Mass(kg) 35000
Overload Range of Gross Vehicle Weight (kg) (Road Condition) < 50000 @ complex road
Overall Dimensions (mm) Wheelbase 3500
Overall Length 5913
Cab Width 2500
Cab Height (Unladen) 3797
Front Overhang 1418
Rear Overhang 995
King Pin Diameter 90#
Min. Ground Clearance 280
Cab Type High-Roof, A/C with Double Sleeper, Auto Tilt
Suspension Mechanical Suspension
Driver Seat Adjustable Seat
Engine Model Sfh® Cursor 9 F2ce3681e×P Made By Saic-Fiat Powertrain Hongyan Co., Ltd.
Cylinder In Line 6
Capacity 8709ml
Turbocharger Inter-cooling
Max. Power (hp/kw)@Rpm 390hp/287kw @2100rpm
Max. Torque (Nm) @Rpm 1590nm @ 1270rpm
Emission Regulation (Euro 4)
Cooling Fan 2 shifts electro-magnetic
Fuel System Bosch® unit pump injector
Gearbox Fast® 12jsd180ta 12 forward shifts and 2 reverse shifts with full synchronizers with Eaton Fuller technology
Clutch Φ430 (17") single plate, diaphragm spiral spring, pull type
Brakes Type 2 independent pneumatic circuits, disc/drum
Parking Mechanical with spring cylinder, rear
Emergency Combined with parking brake
Engine Decompression (exhaust valve brake)
Abs Yes
Suspensions Front Parabolic leaf
Shock Absorbers 2 On Front
Rear Semi-elliptic leaf
Steering Zf® 8098 Power Assisted
Axles Type Hongyan exclusive high-performance H6a axle
Loading Front 9t
Rear 20t+20t
Hub Reduction No
Differential Lock Cross and inter axle
Tyre 12.00r20/315/80r22.5
Fuel Tank 400L steel with lockable fuel cap
Optional
Engine Cursor engine at 350hp, 390hp, 430hp, 480hp
Cab 1. Flat roof
2. Automatic heating rearview mirror
3. Air-suspension design
4. Pneumatic seat
Tractor Unit
Technical Parameters
Model GENLYON CQ4254HTVG324
Driving type 6×4
Weight G.V.W (kg) 25000
Kerb Weight (kg) 8870
Max. Fifth Wheel Payload (kg) 16000
Max. Towed mass(kg) 40000
Overload Range of Gross Vehicle Weight (kg) (Road condition) <55000 on complex road
Overall Dimensions (mm) Wheelbase 3225+1350
Overall Length 6718
Cab Width 2500
Cab Height (unladen) 3832
Front Overhang 1418
Rear Overhang 725
King Pin Diameter 90#
Min. Ground Clearance 280
Cab Type High-roof, A/C with double sleeper,auto tilt
Suspension Mechanical suspension
Driver Seat Adjustable seat
Engine Model SFH® Cursor 9 F2CE0681B×B052 made by SAIC-FIAT Powertrain Hongyan Co., Ltd.
Cylinder 6 in line cylinders
Capacity 8709ml
Turbocharger Inter-cooling
Max Power (hp/kw) @ rpm 380hp/280lw @2100rpm
Max. Torque (Nm) @ rpm 1500Nm @ 1500rpm
Emission Regulation (Euro 3)
Cooling Fan 2 shifts electro-magnetic
Fuel System BOSCH® unit pump injector
Gearbox FAST® 12JSD180TA 12 forward shifts and 2 reverse shifts with full synchronizers with Eaton Fuller technology
Clutch φ430 (17") single plate, diaphragm spiral spring, pull type
Brakes Type 2 independent pneumatic circuits, disc/drum
Parking Mechanical with spring cylinder, rear
Emergency Combined with parking brake
Engine Decompression (exhaust valve brake)
ABS Yes
Suspensions Front Parabolic leaf
Shock Absorber 2 on front
Rear Semi-elliptic leaf
Steering ZF® 8098 power assisted
Axles Type Hongyan exclusive high-performance H6A axle
Loading Front 9T
Rear 20T+20T
Hub Reduction No
Differential Lock Cross and inter axle
Tire 12.00R20/315/80R22.5
Fuel Tank 400L steel with lockable fuel cap
Optional
Engine Cursor engine at 290hp, 310hp, 340hp, 380hp, 430hp, 480hp
Cab 1. Flat-roof
2. Auto-heat rearview mirror
3. Air-suspension
4. Pneumatic seat
Tractor Unit
Technical Parameters
Model GENLYON CQ4255HTVG334
Driving Type 6×4
Weight Gross Vehicle Weight (kg) 25000
Kerb Weight (kg) 8870
Max. Fifth Wheel Payload (kg) 16000
Max. Towed Mass (kg) 40000
Overload range of Gross Vehicle Weight (kg) (road condition) < 55000 on complex road
Overall Dimensions (mm) Wheelbase 3325+1350
Overall Length 6718
Cab Width 2500
Cab Height (unladen) 3832
Front Overhang 1418
Rear Overhang 725
King pin Diameter 90#
Min. Ground Clearance 280
Cab Type High-roof, A/C with double sleeper, auto tilt
Suspension Mechanical suspension
Driver Seat Adjustable seat
Engine Model SFH® Cursor 9 F2CE3681E×P made by SAIC-FIAT Powertrain Hongyan Co., Ltd.
Cylinder (in line) 6
Capacity 8709ml
Turbocharger Inter-cooling
Max. Power (hp/kw)@rpm 390hp/287kw @2100rpm
Max. Torque (Nm) @rpm 1590Nm @ 1270rpm
Emission Regulation (Euro 4)
Cooling Fan 2 speed electro-magnetic
Fuel System BOSCH® unit pump injector
Gearbox Fast® 12JSD180TA 12 forward shifts and 2 reverse shifts with full synchronizers with Eaton Fuller technology.
Clutch φ430 (17") single plate, diaphragm spiral spring, pull type
Brakes Type 2 independent pneumatic circuits, disc/drum
Parking Mechanical with spring cylinder, rear
Emergency Combined with parking brake
Engine Decompression (exhaust valve brake)
ABS Yes
Suspensions Front Parabolic leaf
Shock Absorbers 2 on front
Rear Semi-elliptic leaf
Steering ZF® 8098 power assisted
Axles Type Hongyan exclusive high-performance H6A axle
Loading Front 9T
Rear 20T+20T
Hub Reduction No
Differential Lock Cross and inter axle
Tire 12.00R20/315/80R22.5
Fuel Tank 400L steel with lockable fuel cap
Optional
Engine Cursor engine 290hp, 310HP, 340hp, 380hp, 430hp, 480hp
Cab 1. Flat roof
2. Automatic heating rearview mirror
3. Air-suspension design
4. Pneumatic seat
Genlyon Euro III 4×2 Tractor Unit
Technical Parameters
Model GENLYON CQ4184HTVG351
Vehicle type Tractor
Driving type 4×2
Weights G.V.W. (kg.) 18000
Kerb weight (kg.) 6870
Max. Towed mass(kg) 35000
Overall Dimensions (mm) Length (mm) 5913
Width (mm) 2500
Height (mm) 3797
Wheelbase (mm) 3500
Min. Ground clearance (mm) 280
Performance Parameters Maximum Speed ( km/h ) 120
Economic Speed ( km/h ) 75-95
Maximum Gradability ( % ) 25%
Minimum Turning Diameter ( m ) 6400
Cab   High roof
Engine Model C9 380
Capacity 8709ml
Max power (HP/KW)@rpm 380HP/279KW @2100rpm
Max torque (Nm) @rpm 1500Nm @ 1200-1500rpm
Emission regulation EURO III
Gearbox FAST 12JSD180TA
Clutch φ430 (17")single plate, diaphragm spiral spring, pull type
Drive Axles Type Single Reduction
Ratio 4.11
Frame Section   305*80*8
Suspension   Parabolic
Tyre 11.00R20,12.00R20,315/80R22.5,295/80R22.5
Fuel Tank 400L
Optional
Engine C9 340HP/310HP/290HP
Cab Flat roof
Genlyon Euro III 6×4  Tractor Unit, Right Hand Drive
Technical Parameters
Model GENLYON CQ4254HTVG324
Vehicle type Tractor
Driving type 6×4-RHD
Weights G.V.W. (kg.) 25000
Kerb weight (kg.) 8870
Max. Towed mass(kg) 40000
OVERALL DIMENSIONS (Mm) Overall length (mm) 6718
Cab width (mm) 2500
Cab height (mm) 3832
Wheelbase (mm) 3225+1350
Min. Ground clearance (mm) 280
Performance Parameters Maximum Speed ( km/h ) 110
Economic Speed ( km/h ) 75-95
Maximum Gradability ( % ) 18%
Minimum Turning Diameter ( mm ) 7300
Cab Type High roof
Engine Model C9 380HP
Capacity 8709ml
Max power (HP/KW)@rpm 380HP/279KW @2100rpm
Max torque (Nm) @rpm 1500Nm @ 1200-1500rpm
Emission regulation (EURO III)
Gearbox FAST 12JSD180TA
Clutch φ430 (17")single plate, diaphragm spiral spring, pull type
Frame Section   Single layer,305*80*8mm
Suspensions Front parabolic leaf
Shock absorbers 2 on front
Rear semi-elliptic leaf
Steering power assisted
Drive Axle Type H6A,Single Reduction
Loading 13T+13T
Ration 4.11
Tyre 295/80R22.5 ,315/80R22.5, 11.00R20, 12.00R20
Fuel Tank 400 L
Optional
Engine C9 340HP, C13 430HP
Cab Flat Roof

Tractor Unit

A tractor unit is an articulated vehicle composed of a towing engine or tractor and a trailer that carries the freight. The tractor and trailer are detachable, that is, the tractor can be used to haul other trailers, or vice versa. According to connection type of tractor and trailer, there are full trailer and semi trailer. A full trailer is a trailer that is supported by front and rear axles and pulled by a drawbar. A semi trailer is a trailer that has no front axle and is supported by a road tractor.

SAIC-IVECO HONGYAN mainly produces three types of tractor unit: Hongyan tractor unit, Hongyan Tampa Euro III tractor unit and Hongyan Genlyon National III tractor unit.

Characteristic of Genlyon Tractor
1.Excellent European Surging Power
1) Our IVECO tractor unit is powered by the original Cursor engine, which is tested to be powerful in the European market. The engine features large capacity and great horse power up to 400, available in getting more benefits.
2) Its ECU offers precise control on fuel injection quantity according to the engine speed and the information of accelerator pedal position sensor so as to lower the fuel consumption.
3) Preeminent manufacturing technology gets the brake shoe less worn significantly.

2. Lightweight and High Strength Frame
1) In the front wide and rear narrow structure, this lightweight frame is made of high strength and low carbon alloy steel.
2) The frame integrates 305×80 single-layer beams with variable cross section in optimized assembly design.
3) It has passed the strict and standard test of IVECO, completing 30,000km comprehensive on-road test in the experiment yard and 100,000 times of overload variable load bending tests. There is no crack and deformation. As for torsion test at 1º to 5°, this frame is tested for 100,000 times at each angle without cracking. With outstanding quality, it is guaranteed with long service life and optimized torsion and impact resistance and 50% improved yield strength.

3. Style of Great General
1) This tractor unit introduces the European mature and intelligent CAN bus technology and real-time monitoring workmanship through 6 ECUs. Thus it is easy for drivers to master the running state of the vehicle, keeping driving safety.
2) In the capacious operating cabin that is about 2.2m high inside, drivers gets enough free space to drive joyfully.

4. Working with Great Care
1) Thanks to the meticulous humanized space design of Ferrari designer, this tractor unit offers quiet working environment with low noise for drivers.
2) Totally made of steel that is 1.5mm thick, this cab in bird's nest design is is about 20% lighter than that of domestic heavy trucks, giving comprehensive protection for drivers and passengers.
3) This vehicle is configured with original IVECO core parts in consistency with dedicated manufacturing standard so that its quality is guaranteed.
4) We possess one of only two advanced painting lines with leading precise process in the world.

5. Cost-efficient and Worry-free Performance
1) Main parts of the tractor unit are strictly tested in accordance with European standard.
2) Within warranty period for travelling 24 months or 240,000km, users can feel ease to operate it with maintenance cost saved.
3) This vehicle is characterized by optimal quality and outstanding reliability, ensuring the rate of attendance.
